24V DC Linear Actuator with Controller - Heavy Duty ABS & Aluminum Alloy for Industrial Robots, Automotive, Electric Furniture & Smart Home Automation

Feature:1. Built‑in limit switch, the maximum pushing force is 2000N, easy to operate.2. The maximum load is 3500N, the load speed is about 8mm/s, and low noise.3. Strong power and stable start, suitable for automobiles, machinery industry, robots, etc.4. Linear actuator, uses high‑quality ABS + aluminum alloy, which is and long‑lasting.5. Small size, stable performance, small installation distance and long service life.Specification:Item Type: Linear ActuatorMaterial: ABS+Aluminum AlloyInner Tube: Aluminum TubeHead Mounting Connector: PlasticRear Mounting Connector: Aluminum AlloyWeight: Approx. 2175g / 76.7ozMaximum Pushing Force: 2000NMaximum Pulling Force: 2000NMaximum Load: 3500NMaximum Current: 4.5AmpLoad Speed: 8mm/SInput Voltage: DC24VStroke: 150mm / 5.9inInstallation Direction: H Type or V TypeLimit Switch: Built-InProtection Level: IPX4Noise: <55dB(A)Test Distance: 300mm / 11.8inUse Environment Temperature: 0 - +40℃Size: Approx. 265x133x67mm / 10.4x5.2x2.6inPackage List:1 x Linear Actuator2 x Fixing Accessory2 x Fixing BuckleNotice:1. Please allow 0‑1 inch error due to manual measurement. Thanks for your understanding.2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.3. For full load, the working system of the electric push rod trapezoidal tooth screw is generally 25%. If it is not, it can be increased appropriately. The working system of the ball screw is 100%.4. Balance the lateral force of the push rod to ensure that the electric push rod only bears radial force during operation.5. The length of the telescopic tube should b

Strong power and stable start, suitable for automobiles, machinery industry, robots, etc.

Linear actuator, uses high‑quality ABS + aluminum alloy, which is and long‑lasting.

Built‑in limit switch, the maximum pushing force is 2000N, easy to operate.

Small size, stable performance, small installation distance and long service life.

The maximum load is 3500N, the load speed is about 8mm/s, and low noise.
